5A05 aluminium plate

Category: aluminium plate

Brand: 5A05

Form:O、H112

Click:1207

  • Make to order

  • Original warranty

  • Brand certification

  • Timely delivery

Chat online
Sales call: 0512-67597508
share:
  • Product introduction
  • Chemical composition
  • Product parameters
  • Application cases
  • Related products
Product introduction

5A05 aluminum plate is al-mg antirust aluminum alloy, which cannot be strengthened by heat treatment.The alloy has a high magnesium content and a low strength, similar to the 5A03 aluminum plate.The cold deformation of the alloy can increase the strength but decrease the plasticity.The plasticity in annealing state is higher, while that in semi-cold hardening state is acceptable.The alloy has good corrosion resistance and good weldability, suitable for spot welding, atomic hydrogen welding, gas welding and argon arc welding.Its machinability, annealing state is very poor, semi - cold hardening state is good.

5A05 aluminum plate is usually used to manufacture welding pipes, welded oil tanks and other liquid containers and other parts that require high process plasticity, good corrosion resistance and moderate load;The wire is used for welding rods and rivets, which need to be anodized.In foreign countries, similar alloys (such as 5456) are used to make deck, high strength structural parts.Storage tanks, pressure vessels, and components for Marine supplies.

USES:

5A05 aluminum plate is widely used to make the deck, high strength structural parts.Storage tanks, pressure vessels, and components for Marine supplies.



5A05.jpg 博瑞通.jpg

Chemical composition
alloy designation
硅Si
铁Fe铜Cu锰Mn镁MgCr锌Zn钛Ti锆ZrotherAL
mark

0.50.40.10.3-0.64.8-5.5-0.2--eachtotal
5A05-0.050.15margin











Product parameters
Aluluminium alloy brandstrength of extension/Mpa

yield strength/Mpa

elongation/%hardness
5A05-H1122651151475
