We all know that 6082 aluminum plate is a better mechanical aluminum plate, in fact, its heat dissipation is also better, that in 6082 aluminum plate as a radiator profile in the process of extrusion on the mold requirements?Next 6082 aluminum plate manufacturers to give you an analysis.

6082 aluminum radiator profile molds are many slender teeth, to bear a lot of extrusion pressure, each tooth must have a high strength and toughness, if the difference is very big, it is easy to produce fracture.Therefore, the mold quality must be reliable, it is recommended to use H13 steel, or made of high quality imported steel.There is also a more important process is the mold heat treatment, to use vacuum heating quenching, it is recommended to use this high pressure pure nitrogen quenching, can make the performance of the mold more uniform.

The key to extrude 6082 aluminum radiator profile is to design the mold reasonably and make it accurately.At ordinary times to avoid direct extrusion die working belt.For the comb radiator profile with flat width, the extrusion pressure on the die can be reduced, and the economic pressure can be distributed evenly.As the wall thickness of the outline part of the radiator is large, corresponding to the difference between them, in order to maintain and work, that is, one of the larger wall thickness, in order to work with a specific increase, can be large to the mold design 20 mm ~ 30mm and tooth tip position, in order to break the routine, take work at a minimum.For the flat width radiator, in order to ensure that the mold has a certain stiffness, should increase the thickness of the mold.About 30% of the thickness increased to 60%.The mold size should be accurate, and the empty knife should be symmetrical, with the error less than 0.05mm.

The above is about the requirements of extrusion die when 6082 aluminum plate is used as radiator profile. If you need 6082 aluminum plate, please contact us.
