In the use of 6061 aluminum plate sometimes will take the welding process, that in the 6061 aluminum plate welding may appear when the deformation of the situation, next 6061 aluminum plate manufacturer will introduce to you, 6061 aluminum plate welding deformation solution.

1. Select a reasonable weld size:

Weld size increases, the increase of deformation, but the weld dimension is too small will reduce the bearing capacity of structure and quicken the cooling speed of welding joint, heat affected zone hardness is higher, prone to defects such as cracks, therefore should be meet the structure bearing capacity and under the premise of guarantee the quality of welding, as on the thickness of the aluminum plate process to select 6061 May choose the weld dimension is minimum.

2. Minimize the number of welding seams;

The thickness of 6061 aluminum plate can be appropriately selected to reduce the number of floor plates, so as to reduce the amount of welding seam and the correction amount of post-welding deformation. For example, the plate structure can be replaced by the pressure-shaped structure to reduce the number of welding seam and prevent or reduce the post-welding deformation.

3. Reasonable arrangement of welding seam location:

The weld is symmetrical to the neutral axis of the section of 6061 aluminum plate welds or makes the weld close to the neutral axis can reduce the bending deformation.

4. Reserved shrinkage allowance:

The longitudinal and transverse shrinkage deformation of 6061 aluminum plate welds after welding can be controlled by the estimation of the weld shrinkage amount and the shrinkage margin set aside in advance in the design.

5. Set aside the position of welding fixture:

In order to control the technical deformation in the welding process, the position of welding fixture can be reserved on the 6061 aluminum plate structure.

The welding deformation of 6061 aluminum plate solution is introduced here, if you need 6061 aluminum plate can contact us.
