6063 aluminum plate can be used for building curtain wall, which is well known to us. When 6063 aluminum plate curtain wall is in use, the problem of deformation may occur. 6063 aluminum plate manufacturer will introduce to you several cases of deformation of 6063 aluminum plate curtain wall.

1. First of all, 6063 aluminum plate has no side ribs or middle ribs, causing severe deformation under wind pressure and air tension.

Most of this phenomenon is due to the irregular selection of materials, no side ribs, middle ribs, etc. The curtain wall of 6063 aluminum plate is box-shaped and screwed on the frame directly with screws, and the gap of 6063 aluminum plate plate is coated with glue to calculate the completion.Especially on the sunny side, the air between the slab and the structure wall heats up under the sunlight effect, and the plates deform outwards under the action of air swelling force.

2. The 6063 aluminum plate is fixed with the structural frame of the curtain wall, so the thermal stress cannot release the deformation.

In the large seasonal temperature area of 6063 aluminum curtain wall, the temperature in the lower season falls later in early spring. When the thermal efficiency is strong, the thermal expansion of 6063 aluminum at different temperatures per meter length is more weak than that of the sun. The temperature difference between aluminum plate and frame can be more than 80℃, and the linear expansion difference of 6063 aluminum in the larger size is large.The 6063 aluminum plate with folded edges cannot release the thermal stress, and it deforms outwards under the action of air.

3. Stress deformation occurs during assembly of 6063 aluminum panel and side ribs

In order to solve the thermal stress deformation of the 6063 aluminum plate plate, a rim frame was added around the unit plate plate. In the work site, it was often found that there was a deviation in the folding edge of the face plate groove, and there was a deviation in the assembling frame of the rim profiles. The combination of the two bodies often resulted in either a small frame or an oversized plate hem.For this phenomenon is the deformation of the plate outward at the temperature and the force of expansion of the air.

As for the deformation of 6063 aluminum curtain wall, several cases are introduced here. If you need 6063 aluminum plate, please contact us.
